4x Pylontech US3000C Batteries
1x RJ45 UTP cable 1.8m - ASS030064950
1x Interface MK3-USB - ASS030140000
1x Type A BMS Cable 1.8m - ASS030710118
1x Pylontech Cable Kit
For enhanced control and monitoring, the addition of a Victron GX device, such as the Color Control GX or Cerbo GX with Touch Display, is advisable. This not only facilitates easy setup but also allows for local and remote monitoring of the system’s performance.
Incorporating a 5kW solar system with a suitable solar controller can further augment this setup, leveraging renewable energy for increased efficiency.
Remember, safety is paramount. Ensure this system is installed by a licensed electrician to guarantee compliance with safety standards and optimal performance.
3. Pylontech 14kWh / Victron 8kVa Inverter Charger Off-Grid Starter Bundle
The Victron Energy MultiPlus-II 48/8000/110-100/100 230V Inverter Charger is a powerful and efficient choice for marine electrical systems. Offering 8kVa (6.4kW) of power, combined with 110A DC battery charging and 100A AC transfer capabilities, it provides robust support for energy needs on boats and other marine vessels.
1x MultiPlus-II 48/8000/110-100 230V - PMP482805000
4x Pylontech US3000C Batteries
1x RJ45 UTP cable 1.8m - ASS030064950
1x Interface MK3-USB - ASS030140000
1x Type A BMS Cable 1.8m - ASS030710118
1x Pylontech Cable Kit
The addition of four Pylontech US3000C 48V 3.5kWh Lithium Batteries enhances this system by delivering a substantial 14kW of energy storage. This ensures a reliable and consistent power supply, crucial for marine environments.
For optimal monitoring and control, integrating a Victron GX device is essential. The Color Control GX or Cerbo GX with Touch Display not only allows for straightforward setup and local monitoring but also offers remote monitoring capabilities via the free VRM portal, provided there is internet access.
To further maximize the potential of this system, incorporating up to an 8kW solar system with an appropriate solar controller is recommended. This addition harnesses renewable energy, increasing the system's efficiency and sustainability.
It is crucial to highlight that installation of this system requires a licensed electrician to ensure safety and compliance with all relevant standards.
4. Pylontech 21kWh / Victron 10kVa Inverter Charger Off-Grid Starter Bundle
Victron MultiPlus-II 48/10000/140-100/100 Inverter/Charger
This high-capacity inverter/charger delivers 10kVA (8kW) of power output, with a built-in 140A DC charger and a 100A automatic transfer switch for seamless switching between grid or generator input.
Battery Storage
Paired with 6 × Pylontech US3000C 48V 3.5kWh lithium modules, the system provides a total storage capacity of approximately 21kWh.
Itemised List
1x MultiPlus-II 48/10000/110-100 230V - PMP483105000
6x Pylontech US3000C Batteries
1x RJ45 UTP cable 1.8m - ASS030064950
1x Interface MK3-USB - ASS030140000
1x Type A BMS Cable 1.8m - ASS030710118
1x Pylontech Cable Kit
Included Accessories
All necessary cabling is supplied, along with an MK3-USB interface for programming and configuration of the MultiPlus-II.
Recommended Options
-
System Monitoring & Control: To enable configuration, monitoring, and remote access, we recommend adding a Victron GX device (Cerbo GX with Touch display or Color Control GX). This allows local system management as well as remote monitoring via the free VRM portal (internet connection required).
-
Solar Integration: The setup is designed to work with up to an 8kW solar array when paired with a suitable Victron solar charge controller.
Please note:
Delivery is available to business addresses or Border Express depots. Residential addresses may be accepted, however an additional charge may apply.
