SEAKEEPER RIDE 525 Seakeeper Ride Underway Stabilization

Eliminate up to 70% pitch and roll underway

Nothing compares to the first-of-its-kind Vessel Attitude Control System, Seakeeper Ride, which can eliminate up to 70% pitch and roll underway. Our proprietary, rapid-deployment rotary blades make 100 adjustments every second to combat wave motions, providing unmatched performance.

How it works

Seakeeper Ride controllers are mounted to your boat’s transom, below the waterline. Using custom, proprietary inertial sensing hardware and software, the system understands how the boat is behaving in all three axes and commands deployment of the rotary blades to counteract pitch, roll, and yaw. As the blades are deployed, they create lift at the transom, managing the vessel’s motion instantaneously.

Why it’s better

Wave motions can happen consistently or inconsistently, they can be big or small, and can come from any direction. Often, these motions occur in just milliseconds. Thanks to expert control software and hardware, Seakeeper Ride’s proprietary, rapid-deployment rotary blades make 100 adjustments every second to combat wave motions.

Nothing compares to the first-of-its-kind Vessel Attitude Control System, Seakeeper Ride, which can eliminate up to 70% pitch and roll underway.

Additional
Features

Rapid Actuation

Rotary blades deploy at a rate of up to 300 mm per second, making 100 adjustments every second; enabled by power-dense rotary design that requires just 7-10 Amps for operation.

Full Underway Control

Controls all motions (pitch, roll, yaw) thanks to deployment speed and proprietary control software and hardware.

Intuitive

Predicts motion and responds instantaneously to eliminate them before they’re felt with no buttons to push nor adjustments to make, providing a boating experience you never imagined.

Reliable

Drivetrain is completely sealed in a dry and greased environment with no mechanical exposure to saltwater.

Simple Installation

Easily installed on most transoms, both in new and aftermarket boats.

What's included:

(2) Port and Starboard Controllers

Seakeeper Ride controllers are installed on the transom on either side of the engine(s)

Software Module

The “brain” of the system that includes Seakeeper’s proprietary software and motion sensors

Distribution Module

Provides power and communication between the controllers and the software module

User Interface

User Interface is compatible with select Garmin, Simrad and Raymarine MFDs. MFD is not included in Seakeeper Ride equipment.

Optional Extra:

Keypad (Optional)

Physical, mountable keypad that can be used outside of the MFD application

Specifications:
