Take the guesswork out of your installation. This professionally drawn schematic outlines a complete 12V off-grid power system using Victron and Fusion components. These wiring diagrams are related to our packs.
The layout includes all key system connections between:
1x MultiPlus-II 12/5000
1x SmartSolar MPPT 100/50
3x EE Lithium 12V 240Ah Lithium Battery
1x Lynx Distributor (M10) – LYN060102010
1x Cerbo GX MK2 – BPP900451100
1x GX Touch 50 – BPP900455050
1x SmartShunt 500A/50mV IP65 – SHU065150050
1x RJ45 UTP cable 1.8m – ASS030064950
2x VE.Direct cable 1.8m – ASS030530218
1x SmartSolar MPPT 100/50
3x EE Lithium 12V 240Ah Lithium Battery
1x Lynx Distributor (M10) – LYN060102010
1x Cerbo GX MK2 – BPP900451100
1x GX Touch 50 – BPP900455050
1x SmartShunt 500A/50mV IP65 – SHU065150050
1x RJ45 UTP cable 1.8m – ASS030064950
2x VE.Direct cable 1.8m – ASS030530218
