Name: Wiring Diagram - 48v Off-Grid Pack | Victron & Energy Eco Semi-Solid State Lithium Pack 1
Brand: Energy Eco
SKU: EE48schematic1
Price: 91.67 AUD
Availability: InStock

Wiring Diagram - 48v Off-Grid Pack | Victron & Energy Eco Semi-Solid State Lithium Pack 1

$91.67 $128.75

Take the guesswork out of your installation. This professionally drawn schematic outlines a complete 48 V off-grid power system using Victron and Energy Eco components — ideal for compact sheds, cabins, or mobile applications. These wiring diagrams are related to our packs.

The layout includes all key system connections between:

1x MultiPlus-II 48/3000/35-32 230V - PMP482305012

1x SmartSolar MPPT 100/20 - SCC110020160R

1x Energy Eco 48V 5.12KWH Semi-Solid State Lithium Battery

1x Lynx Distributor (M10) - LYN060102010

1x Cerbo GX MK2 - BPP900451100

1x GX Touch 50 - BPP900455050

1x RJ45 UTP cable 1.8m - ASS030064950

1x Ve.Direct cable 1.8m - ASS030530218

1x Type B BMS Cable 1.8m - ASS030720018

1x Cable Kit

It also details the required but not-included protective components, cable diameter for cable (app is included for this) and solar panel connection limits. We are here for assistance with this if needed after purchase.

Perfect for installers, DIY builders, and anyone wanting a clear, safe, and standards-based wiring plan for a modern 48 V Victron-Energy Eco system Pack 1.

Once purchased, the wiring diagram will be emailed to you.
