Take the guesswork out of your installation. This professionally drawn schematic outlines a complete 48 V off-grid power system using Victron and Energy Eco components. These wiring diagrams are related to our packs.
The layout includes all key system connections between:
1x MultiPlus-II 48/5000/70-50 230V - PMP482505010
1x SmartSolar MPPT 150/45 - SCC110020160R
2x Energy Eco 48V 5.12KWH Semi-Solid State Lithium Battery
1x Lynx Distributor (M10) - LYN060102010
1x Cerbo GX MK2 - BPP900451100
1x GX Touch 50 - BPP900455050
1x RJ45 UTP cable 1.8m - ASS030064950
1x Ve.Direct cable 1.8m - ASS030530218
1x Type B BMS Cable 1.8m - ASS030720018
1x Cable Kit
1x SmartSolar MPPT 150/45 - SCC110020160R
2x Energy Eco 48V 5.12KWH Semi-Solid State Lithium Battery
1x Lynx Distributor (M10) - LYN060102010
1x Cerbo GX MK2 - BPP900451100
1x GX Touch 50 - BPP900455050
1x RJ45 UTP cable 1.8m - ASS030064950
1x Ve.Direct cable 1.8m - ASS030530218
1x Type B BMS Cable 1.8m - ASS030720018
1x Cable Kit
