Take the guesswork out of your installation. This professionally drawn schematic outlines a complete 48 V off-grid power system using Victron and Energy Eco components. These wiring diagrams are related to our packs.
The layout includes all key system connections between:
1x MultiPlus-II 48/8000/110-100 230V – PMP482805000
1x SmartSolar MPPT 250/85-Tr – SCC125085411 (to handle higher PV input)
3x Energy Eco 48V 5.12kWh Semi-Solid State Lithium Battery (15.36kWh total)
1x Lynx Distributor (M10) – LYN060102010
1x Cerbo GX MK2 – BPP900451100
1x GX Touch 50 – BPP900455050
1x RJ45 UTP cable 1.8m – ASS030064950
1x VE.Direct cable 1.8m – ASS030530218
1x Type B BMS Cable 1.8m - ASS030720018
1x Cable Kit
